Nihal Meena

There is a 5 meters decrease in length of tracker in pvsyst because it only uses modules for tracker creation will this effect the results.

This process might be time-consuming. Is there another way to incorporate the motor gap and pile gap in the tracker?

Hello, Can we incorporate parameters such as motor gap and piles gap in the near shading when creating the array of trackers? This way, the length of the trackers generated in the shading scene will align with the length of the trackers in my layout, accounting for these gaps.

Hello @Muhammed Sarikaya, Thank you for the update. I followed your instructions and changed the unit to millimeters while importing the 3D scene into PVSyst. The model was successfully imported, but the size appears to be very small. The total number of modules is showing as 0, and the area of the 3D field is less than the module size defined in the system.

I have created a CAD file and a .PVC file using PVcase, where my trackers and trees follow the terrain of a specific geography. However, when I try to import the .PVC file into PVsyst, I receive an error. In my assessment, it appears that the error may be attributed to the challenging terrain conditions. I will share the .PVC file if requires.

Hey PVsyst Team, I have created a CAD file and a .PVC file using PVcase, where my trackers and trees follow the terrain of a specific geography. However, when I try to import the .PVC file into PVsyst, I receive a message stating, 'Your 3D scene is too large and cannot be imported.' Interestingly, the same scene is successfully imported when I remove some of the trees.
